MAAP #221: Illegal mining in protected areas of the Ecuadorian Amazon

Posted on by Matt Finer
Mapa Base. Áreas protegidas en la Amazonía ecuatoriana amenazadas por minería.

In a series of previous reports, we warned about the emergence and expansion of mining deforestation in the Ecuadorian Amazon (MAAP #151, MAAP 182, MAAP #219).

Illegal mining in Ecuador tends to operate in remote areas, such as protected areas.

Furthermore, this activity’s proximity to Colombia and Peru facilitates cross-border flows essential for the gold trade.

Here, we analyze the four protected areas in the Ecuadorian Amazon that are currently threatened by mining activities: Podocarpus and Sumaco Napo-Galeras National Parks, Cofán Bermejo Ecological Reserve, and El Zarza Wildlife Refuge (see Base Map).

The mining is occurring deep within Podocarpus National Park.

In the other three areas (Sumaco Napo-Galeras National Park, Cofán Bermejo Ecological Reserve, and El Zarza Wildlife Refuge), unregulated mining activities are expanding in their buffer zones and starting to penetrate their respective boundaries.

Below, we present a concise analysis of these four affected protected areas, featuring high-resolution satellite imagery.







Podocarpus National Park

We analyzed the illegal mining activities along the Loyola River within Podocarpus National Park. We first detected the mining deforestation of 22 hectares in July 2023. By September 2024, this impact had increased to 50 hectares (124 acres), resulting in an illegal expansion of 125% within the park between 2023 and 2024 (Figure 1).

Figura 1. Deforestación minera a orillas del río Loyola al interior del Parque Nacional Podocarpus, julio 2023 (panel izq) vs agosto 2024 (panel der).
Figura 1a. Imagen Skysat de deforestación minera del río Loyola al interior del Parque Nacional Podocarpus,

In addition, we used a very high-resolution image (SkySat, 0.50 meters) from March 25, 2024, to visualize the pattern and impact of the illegal mining in greater detail.























Sumaco Napo – Galeras National Park

We have continuously monitored the expansion of illegal mining in the Punino River basin ((MAAP #151, MAAP #219).) and its advance towards Sumaco Napo-Galeras National Park. In May 2024, we first detected the penetration of illegal mining across the park’s southeastern boundary.

We estimate the expansion of 142 hectares (350 acres) in the park’s buffer zone, between September 2022 and August 2024. We also just detected the penetration (0.32 hectares) of illegal mining into the park’s boundaries (Figure 2).

Figura 2. Deforestación minera en el Parque Nacional Sumaco Napo-Galeras, septiembre 2022 (panel izq) vs agosto 2024 (panel der).

Cofán Bermejo Ecologial Reserve

In MAAP #186, we showed how mining activities along the Bermeja River threaten the boundaries of the Cofán Bermejo Ecological Reserve in the northern Ecuadorian Amazon. In this area, a total mining advance of 337 hectares (833 acres) was recorded during the period from February 2020 to September 2024, of which it was estimated that 1.05 hectares (2.6 acres) are within the boundary of the Cofán Bermejo Ecological Reserve (Figure 3).

Figura 3. Deforestación minera en la Reserva Ecológica Cofán Bermejo, feb 2020 (panel izq) vs sept 2024 (panel der).

El Zarza Wildlife Refuge

We detected mining activities along the Zarza River impacting 33 hectares (82 acres) in the buffer zone of the El Zarza Wildlife Refuge (Figure 4).

Figura 4. Deforestación minera en la zona de amortiguamiento del Refugio de Vida Silvestre el Zarza, septiembre 2022 (panel izq) vs agosto 2024 (panel der).

Acknowledgements

This report is part of a series focused on the Ecuadorian Amazon through a strategic collaboration between the EcoCiencia Foundation and Amazon Conservation, with the support of the Norwegian Agency for Development Cooperation (Norad).

Ecociencia Logo

MAAP #207: Removing Illegal Mining from Sacred Tepui in Yapacana National Park (Venezuelan Amazon)

Posted on by Lauren deVilla

Last year,  in collaboration with the organization SOS Orinooco, we published an urgent report about illegal mining on top of a sacred tepui in the heart of Yapacana National Park in Venezuela (MAAP #169).

Tepuis are stunning table-top mountains found in northern South America. They are considered sacred by indigenous groups of the region; in fact, the word tepui means “house of the gods” in a local indigenous language. Tepuis also have high levels of endemism (unique species) since they are not connected to other ranges.

In that report, we documented 425 illegal mining data points (consisting of mining camps and machinery) on top of the tepui, indicating an organized and large-scale operation on top of this critically important biogeographical site.

Given the importance of this finding, the Washington Post published a high-profile article on the subject (see right), further exposing the severity of the illegal mining on the tepui.

In response, the Venezuelan government conducted a military operation (led by the Operational Strategic Commander of the Armed Forces) against illegal mining activity on the tepui in December 2022.

Here, we show a series of very high-resolution satellite images taken during the raid (December 2022) versus one year later (January 2024).

The images reveal that all illegal mining camps and equipment on top of the tepui have been effectively dismantled. That is, we went from 425 visible illegal mining camps and heavy equipment in December 2022 to zero in January 2024.

This removal of illegal mining activity from the tepui marks an important victory for Amazon conservation in Venezuela. However, as also detailed below, we show illegal mining continues in surrounding areas within and outside the Yapacana National Park.

Illegal Mining on the Tepui
Before vs After the Government Operation

The Figure 1 (see below) shows an aerial view of the tepui as of December 2022, surrounded by the lowland rainforest of Yapacana National. The white indicates the illegal mining activity occurring on the tepui and in the park (not including the whispy clouds passing the tepui).

Insets A-D indicate the locations of the four zooms, where we show a series of very high-resolution satellite images taken during the raid (December 2022) versus one year later (January 2024). Note that in each image, there is clear evidence of mining camps in December 2022 (left image) vs. no remaining mining camps in January 2024 (right image).

Figure 1. Former active mining sites on top of tepui in Yapacana National Park. Data: Planet/Skysat, ACA/MAAP.

Yapacana Tepui, Zoom A.

Yapacana Tepui, Zoom B.

Yapacana Tepui, Zoom C.

Yapacana Tepui, Zoom D.

Mining Continues in Yapacana National Park

Figure 2. Active mines in and around Yapacana National Park. Data: Planet/NICFI, ACA/MAAP.

While above we credit the Venezuelan government for removing illegal mining activity from the top of the tepui, in this section we note that illegal mining is still occurring in multiple sites within and around Yapacana National Park (see Figure 2).

Below we show a series of satellite images of illegal mining camps and equipment in several of these continuing active sites: Cacique, Cerro Moyo, and Yagua.

Cacique

The Cacique site, located in the southern sector of Yapacana National Park close to the tepui, we recently observed what appears to be a cluster mining camps.

Figure 3. Zoom of Cacique mining site, within Yapacana National Park. Data: Planet/Skysat, ACA/MAAP.

Cerro Moyo

At the Cerro Moyo site, located in the northwest sector of Yapacana National Park, we see both mining camps and equipment.

Figure 4. Zoom of Cerro Moyo mining site, within Yapacana National Park. Data: Planet/Skysat, ACA/MAAP.

Yagua

Note the Yagua site is located just outside the southeast sector of Yapacana National Park, but is also illegal (all mining within Amazonas province is prohibited by law). At this site we see abundant mining equipment.

Figure 5. Zoom of Yagua mining site, outside of Yapacana National Park. Data: Planet/Skysat, ACA/MAAP.

Reconhecimentos

We thank the organization  SOSOrinoco for important information and comments related to this report.

Citação

Finer M, Ariñez A (2024) Dismantling Illegal Mining from Sacred Tepui (Venezuelan Amazon). MAAP: 207.

MAAP #206: Rapid expansion of illegal mining in Ecuadorian Amazon

Posted on by Lauren deVilla

In a series of previous reports, we warned about the emergence of alluvial mining in the Ecuadorian Amazon, specifically in the area around the Punino River, located between the provinces of Napo and Orellana (MAAP #151, MAAP #182).

Here, we highlight the rapid growth of mining activity in the Punino area: 784 hectares in 2023, which represents a striking increase of 261%.

This mining activity is mainly dedicated to the extraction of gold.

The vast majority of the detected activity is illegal mining, as it is outside the limits of the areas authorized for mining. For example, note the threat that illegal mining represents for the newly created El Chaco Municipal Conservation Area (see Base Map).









Rapid expansion of mining deforestation in 2023

Image 1 emphasizes the rapid expansion of mining deforestation in the Punino area in 2023 (red), relative to the previous three years (yellow).

The yellow indicates the mining deforestation of 217 hectares between November 2019 and December 2022, while the red shows the rapid expansion of 784 hectares (1,937 acres) from January to December 2023.

Thus, in total, the forest area affected by mining activity is 1,001 hectares (2,474 acres), from 2019 to the present.

Moreover, Image 1 clearly shows that the majority of mining deforestation is located outside the limits of authorized mining areas (purple). Specifically, we estimate that 90.4% of the total affected area (904 hectares, or 2,234 acres) represent illegal mining.

Image 1. Dynamics of mining activity between 2019 and 2023 in the Punino area. Data: Planet-NICFI, EcoCiencia.

Graph 1 shows the rapid escalation of mining deforestation in 2023 (bars 2, 3 and 4) relative to the previous three years (bar 1).

Graph 1. Deforestation due to mining in the Punino area between 2019 and 2023

Image 2 shows, with high-resolution satellite images, the expansion of mining deforestation in the Punino area between December 2022 (left panel) and December 2023 (right panel). The red arrows indicate the main areas of mining expansion.

Image 2.

Acknowledgments

This report is part of a series focused on the Ecuadorian Amazon through a strategic collaboration between the organizations EcoCiencia Foundation and Amazon Conservation, with the support of the Norwegian Development Cooperation Agency (Norad).

MAAP #206: Direct Link Emerges between Mennonites and Potential Large-scale Deforestation in Suriname

Posted on by Lauren deVilla

In the recent MAAP #203, we reported that the government of Suriname is preparing to clear large tracts of Amazon rainforest for agriculture.

Specifically, we estimated that a shocking 451,000 hectares (1.1 million acres) of primary forest were threatened in the proposed agricultural plots.

Intertwined with this issue are additional reports indicating that groups of Mennonites are in the process of relocating to Suriname from Bolivia. This raised alarms given the extensive large-scale agriculture deforestation caused by Mennonites in the Amazon regions of both Peru and Bolivia.

Here we report the first evidence directly linking the Mennonites with potential large-scale deforestation in Suriname.

As background, the agricultural real estate company Terra Invest is responsible for all aspects of the project to bring select Mennonites families to Suriname from Bolivia1. As detailed in the Bolivian news outlet Nomadas, the Suriname government would grant the agriculture land to Terra Invest, who would then transfer the land to societies formed by Mennonites in Suriname.

Newly leaked government documents, from Suriname’s Ministry of Land and Forest Management dated to February 2023, provide the first available spatial data on the location of proposed lands to Terra Invest.

These lands are broken down into three separate areas, totaling 78,775 hectares.

The Base Map shows these Terra Invest request areas (purple) in relation to the previously published information on proposed agricultural plots to the Ministry of Agriculture and Foundations backed by private land developers.

Potential Primary Forest Loss

We performed an additional analysis looking at how much primary forest is contained and threatened in these proposed agriculture plots to Terra Invest. This analysis was based on data from the University of Maryland and Global Forest Watch.

In Figure 2, we show that the proposed Terra Invest plots threaten 76,932 hectares of primary forest. Note that 8,991 hectares of primary forest overlaps with Kaboeri Creek Nature Preserve.

We also that of the above total, 22,675 hectares of primary forest are in addition to what was previously calculated for the Ministry of Agriculture lands. Thus, we now estimate that 473,675 of primary forest are threatened across all three types of proposed agriculture plots (Terra Invest, Ministry of Agriculture, and Foundations).

Notes

  1. Bolivian mennonites bring the «hell» of deforestation to Suriname

Citation

Finer M, Goedschalk J, Arinez Z (2024). Direct Link Emerges between Mennonites and Potential Large-scale Deforestation in Suriname. MAAP: 206.

MAAP #203: Massive Planned Deforestation in Amazon of Suriname

Posted on by Lauren deVilla

In a recent article, the environmental science news platform Mongabay reported that, according to their review of official documents, the government of Suriname is preparing to clear large tracts of Amazon rainforest for agriculture.

Mongabay reported that a massive amount of land (365,704 hectares, or 903,674 acres) was being targeted for new agriculture plots being established for the Ministry of Agriculture (354,836 hectares) and private land developers (10,868 hectares).

This is additionally noteworthy because large-scale agriculture is not historically or currently a deforestation driver in Suriname, so these new plots would likely trigger unprecedented forest loss in one of the world’s few remaining countries dominated by primary rainforest.

Intertwined with this issue are additional reports indicating that groups of Mennonites are planning to relocate to Suriname. This news has also raised alarms given the extensive deforestation caused by Mennonites in the Amazon regions of both Peru (7,032 hectares) and Bolivia (210,980 hectares).

In their article, Mongabay gathered information from the government documents to create a map of the proposed agriculture plots. We then digitized this map, calibrated it with coordinates in the documents, and then conducted our own analysis.

The Base Map shows our digitized map of the agricultural plots, with the inclusion of protected areas and Indigenous & Tribal Peoples villages, all overlayed on top of a recent satellite image.

We estimate 467,000 hectares in the proposed new agricultural plots (456,238 ha for the Ministry of Agriculture and 10394 ha for Foundations backed by private land developers). Note this is substantially higher than the estimate reported by Mongabay. Additional analysis of the documents indicates that the actual total could rise to 560,000 hectares.

Potential Primary Forest Loss

We performed an additional analysis looking at how much primary forest is contained and threatened in these proposed agriculture plots. This analysis was based on data from the University of Maryland and Global Forest Watch.

In Figure 2, we estimate 451,000 hectares of threatened primary forest in the proposed agriculture plots (441,362 ha for the Ministry of Agriculture and 9,958 ha for Foundations backed by private land developers).

This would result in a shocking amount of primary forest loss for a country that has experienced an average annual deforestation of 6,560 hectares over the past 21 years (137,746 hectares in total since the year 2002).

Citation

Finer M, Goedschalk J, Arinez Z (2024) Massive Planned Deforestation in Amazon of Suriname. MAAP: 203.

MAAP #202: Protecting Strategic, Free-flowing River Corridors in the Ecuadorian Amazon

Posted on by Lauren deVilla
Aerial photo of a section of the proposed river conservation corridor, highlighting some of the key components of the proposal: free-flowing river, intact riparian forest, and sustainable, low-impact tourism. Photo credit: Wil Henkel

Here, we present a model river conservation strategy proposed by the Ecuadorian Rivers Institute, designed to protect strategic free-flowing river corridors with intact surrounding forests in the critical transition zone between the Andes mountains and the Amazon lowlands.

The vision is to conserve freshwater resources and their surrounding riparian forests, encourage sustainable economic alternatives, and preserve free-flowing ecological connectivity at the basin scale.

There are few remaining high-quality and ecologically intact Andean-Amazon watershed corridors in Ecuador, making their protection and management an urgent national priority, ideally as part of a larger global tropical river conservation strategy

The proposal targets strategic corridors that have three major characteristics:

  1. Free-flowing rivers with no dams, diversions, or channel modifications, and no mining or dredging.
    h
  2. High-quality rivers that are a reference for water quality and have exceptional natural and cultural values.
    j
  3. Forested riparian buffer zones to preserve the quality and integrity of the river corridor, enhance the ecological connectivity between protected areas, and preserve habitat throughout critical transition zones.

These core components provide the key elements that are needed to preserve, restore, and enhance the integrity of the freshwater biodiversity, aquatic ecosystems, and scenic landscapes of strategic, free-flowing river corridors in the tropical Andes.

Priorities for River Protection in Ecuador

Base Map. Proposed free-flowing and intact riparian forest corridors (highlighted in yellow) in the northern Ecuadorian Amazon. Data: ERI.

The Base Map illustrates two proposed pilot projects in the northern Ecuadorian Amazon. Both represent key habitats for native fisheries and migratory birds and are important destinations for sustainable ecotourism activities. Following these two examples, national, regional (Amazon-scale), and global river protection programs could be created to include additional watershed corridors.

Jondachi-Hollín-Misahuallí-Napo River Corridor

The Jondachi and Hollín Rivers are major free-flowing tributaries of the Misahuallí River sub-basin in the Napo River watershed. These rivers drain from the Antisana and the Sumaco Napo Galeras National Parks, and provide strategic connectivity in a critical transition zone between montane cloudforests and lowland rainforest.

The proposed corridor would protect 200 km of free-flowing rivers and 19,050 hectares of riparian forest (with the application of 500m-wide buffers) within the Sumaco Biosphere Reserve. A significant portion of the corridor is within a forest reserve to provide enhanced connectivity and protection. The proposed corridor is an established destination for a variety of low-impact ecotourism activities that provide significant benefits to the local economy.

Piatúa River Corridor

The Piatúa River is another world-class paddle sports ecotourism destination that is renowned for its natural bathing areas with crystal clear water and sculpted granite boulders. The Piatúa River is a tributary of the Anzu River sub-basin of the Napo River watershed, which drains out of rugged paramo tundra and montane cloud forests deep within the Llanganates National Park, and provides critical ecosystem connectivity through a wide elevation range with high levels of endemic species.

The proposed corridor would protect 46 km of free-flowing rivers and tributaries and 947 hectares of riparian forest (with the application of a 100m-wide riparian buffer)

River Conservation Strategy

Guidelines for Protection

Legally binding frameworks are needed which restrict the development of intensive land-use activities and hydraulic infrastructure, and guarantee high-level, permanent protection of natural river corridors and natural instream flow regimes, with riparian buffer zones to preserve aquatic habitat and water quality. Ecuador has an existing framework which can be used to designate protected river corridors with the same status as national parks. However, until now it has only been applied to protect small catchment basin areas for sources of drinking water in headwater tributaries.

Management recommendations

Comprehensive management plans must be developed with meaningful public participation, and provisions for monitoring, control and enforcement of restricted activities. Independent monitoring and evaluation is necessary to ensure adequate compliance and implementation is achieved. Academic institutions should be encouraged to participate and develop research programs which reinforce the management objectives.

Social component

The successful implementation of the proposed river protection strategy depends on the active participation and endorsement by the local population and people who use the resource, along with adequate governance, and sufficient funding for management and incentives.

Protecting the river corridor ensures sustainable economic benefits for the inhabitants of the region through low-impact ecotourism activities (such as kayaking, rafting, mountain biking, bird watching, and hiking) which are compatible with the management of the resource.

However, additional financial incentives (such as land grants) are needed to reach other sectors of the population in order to take pressure off of the increasing encroachment into the forested riparian corridors for timber harvesting and subsistence-level agricultural expansion.

Ongoing support and guidance is also needed for local communities and landowners to identify employment opportunities and encourage other sustainable production activities in order to optimize the use of degraded areas outside of the protected riparian buffers.

In the case of plastic recycling, the population of Ecuador has responded favorably to adapting cultural and behavioral norms in response to small incentives created by a tax on plastic beverage containers, to address a significant waste management issue. This is a positive sign for what to expect if incentives are provided for protecting natural river corridors.

Financial mechanisms

Securing long-term financial commitments is a fundamental component to ensure the viability of any natural resource protection program. Most developing countries are burdened by foreign debt and are struggling to meet their fiscal obligations and priorities, which often lessens priorities for environmental management. However, experience has shown that the international community responds favorably to reinforce commitments made by host countries to preserve natural and cultural heritage of global significance, and debt forgiveness and debt reduction transactions for host country governments, from wealthy countries would be expected to provide some funding for the proposed strategy to protect strategic free-flowing river corridors in Ecuador.

The Government of Ecuador is facing a critical economic situation. However, water conservation funds have been successfully implemented to cover the cost of managing the protection of drinking water sources for metropolitan areas by including a small environmental management fee on monthly water bills. Some of these water conservation funds have generated substantial levels of endowment to the point where they could have the potential to provide funding for the protection of strategic river corridors, if that was authorized by the water fund consortium.

While the outcome of COP28 may have put a temporarily damper on the value of the nascent carbon credit market, once the programs are restructured to provide for improved accountability and implementation, the expectations for carbon credits to provide a source of long-term funding for the protection and management of strategic free-flowing river corridors as a climate mitigation strategy are quite encouraging, as are expectations for eventual funding allocations for river protection to be derived from the COP21 Paris Climate Accord, and the Global Environmental Facility (GEF).

Meanwhile, voluntary contributions from hydroelectric projects and extractive projects to offset their impacts by designating a percentage of annual income from the generation of electricity for the protection of free-flowing river corridors.

Likewise, voluntary contributions from international finance institutions based on a percentage of annual revenue disbursed through their investment portfolio could provide meaningful support for the protection of free-flowing river corridors, once these agreements are established.

Annex

Herre is a recent satellite image of the Jondachi-Hollín-Misahuallí-Napo River Corridor. Note the intact river and forest core to the east of the major road network, and north of the Napo River.



Citation

Terry M, Finer M, Ariñez A (2023) Protecting Free-flowing & Intact River Corridors in the Ecuadorian Amazon. MAAP: 202.

MAAP #199: Amazon Carbon Update, based on NASA’s GEDI Mission

Posted on by Lauren deVilla

As we approach the COP28 climate summit, starting in Dubai in late November, we provide here a concise update on the current state of remaining Amazon carbon reserves.

We present the newly updated version of NASA’s GEDI data1, which uses lasers aboard the International Space Station to provide cutting-edge estimates of aboveground biomass density on a global scale.

Here, we zoom in on the Amazon and take a first look at the newly updated data, which covers the time period of April 2019 – March 2023.2

This data, which is measured in megagrams of aboveground biomass per hectare (Mg/ha) at a 1-kilometer resolution, serves as our estimate for aboveground carbon reserves.

Figure 1 displays aboveground biomass across the Amazon biome. Note the highest carbon densities (indicated in bright yellow) are located in both the northeast Amazon and southwest Amazon.

Aboveground Biomass across the Amazon

Figure 2 also displays aboveground biomass across the Amazon biome, but this time with country boundaries and labels added.

Note that the peak biomass concentrations in the northeast Amazon include Suriname, French Guiana, and the northeast corner of Brazil. The peak biomass concentrations in the southwest Amazon are centered in southern Peru. Also note that many parts of Ecuador, Colombia, Venezuela, Guyana, Bolivia, Brazil, and northern Peru have high carbon densities as well.

Figure 2. Aboveground biomass density (carbon estimate) across the Amazon biome, with country boundaries. Data: NASA/GEDI, NICFI.

Carbon Estimates

We calculated over 78 billion metric tons of aboveground biomass across the Amazon biome (78,184,161,090 metric tons to be exact). Using a general assumption that 48% of this biomass is carbon3, we estimate over 37 billion metric tons of carbon across the Amazon (37,528,397,323 metric tons).

Note that these totals are likely underestimates given that the laser-based data has not yet achieved full coverage across the Amazon (that is, there are many areas where the lasers have not yet recorded data, leaving visible blanks in the maps above).

This is consistent with a previous study based on another independent dataset, where we estimated 6.7 billion metric tons of carbon in the Peruvian Amazon as of 2013 (MAAP #148). The current GEDI data estimates at least 5.3 billion metric tons in the Peruvian Amazon.

Carbon Sink

In a previous report, we showed that the Brazilian Amazon has become a net carbon source, whereas the total Amazon is still a net carbon sink (MAAP #144). Our current report goes one step further in terms of showing just how much carbon is left in that sink.

Notes

1GEDI L4B Gridded Aboveground Biomass Density, Version 2.1. https://daac.ornl.gov/cgi-bin/dsviewer.pl?ds_id=2299

2Note that we previously reported on the initial data release, which covered the time period of April 2019 – August 2021 (see MAAP #160).

3Domke et al (2022) How Much Carbon is in Tree Biomass?. USDA/Forest Service.

Acknowledgements

This work was supported by NORAD (Norwegian Agency for Development Cooperation) and ICFC (International Conservation Fund of Canada).

Citation

Mamani N, Finer M, Ariñez A (2022) Amazon Carbon Update, based on NASA’s GEDI Mission. MAAP: 199.
